Appleton Tray Cable Connectors

Now certified for use with non armored cords and cables including tray cable types tc tc er tc er hl itc er and more.

Appleton tray cable connectors.

Tray cable connector type straight hub size 1 inch cable type tray cable cable size 0 67 to 0 85 inch insert 0 85 to 1 04 inch no insert diameter 1 95 inch length 1 96 inch constructional feature explosion proof material copper free 4 10 of 1 percent max aluminum application ordinary dry wet hazardous and non hazardous location approval ul 514b 2225 csa c22 2 can csa. Cut jacket armor and fillers to expose the desired length of conduc tor. Appleton tc050055nb tray cable connector 1 2 0 41 0 55 diameter brass tray cable connector 1 2 inch 0 41 0 55 inch diameter brass nickel plated suitable for use with type tc cable and flex cord in ordinary wet and hazardous locations. Designed for use with appleton.

Cableready connectors for metal clad and tray cable tmc for non hazardous locations tmcx for hazardous locations tmc installation tmcx installation prepare cable. Service entrance cable connector 1 1 2 zinc die cast emt compression connector steel 2 inch 3 4 self drilling screw. Tc cable connector tray cable entry thread c cable range insert mm in a cable range no insert mm in b catalog number aluminium np brass stainless steel optional pvc npt npt option min max min max shroud 1 2 3 3 0 13 7 1 0 28 tc050028 tc050028nb tc050028ss pvc05 3 4 tc075028 tc075028nb tc075028ss 1 2. Appleton tcgc cable tray ground clamp cable tray grounding conductor clamp material.

Copper free aluminum finish. Tray cable connector type straight hub size 1 2 inch cable type tray cable cable size 0 26 to 0 41 inch insert 0 41 to 0 55 inch no insert diameter 1 3 inch length 1 57 inch constructional feature explosion proof material copper free 4 10 of 1 percent max aluminum application ordinary dry wet hazardous and non hazardous location approval ul 514b 2225 csa c22 2 can csa. Strip off outer jacket. Electro tinplated for 6 2 0 awg grounding wire.

Appleton tc cable connectors are suitable for use with type tc tray cable and flex cord in ordinary wet and hazardous locations including class i division 2 where permitted by code class i zone 1 aex e and ex e where permitted by code. They offer ingress protection to nema 4x and ip66 67 68. Use of non ferrous or nonmetallic box connectors locknuts and bushings and installation of non magnetic panel inserts is suggested in the code. We ve got appleton tc075079 tray cable connector explosionproof size 3 4 diameter 0 47 0 61 at wholesale prices at rexel usa register now.
